Constant Heat Sealer 600mm

Pacplus 600mm Treadle-Operated Industrial Constant Heat Sealer

Brand: Pacplus

Product Overview:

The Pacplus CCHS600 is a wide-format, continuous-heat packaging machine built to fuse dense barrier foils, coated papers, and heavy-duty gusseted sacks. Actuated via a mechanical foot treadle to keep both hands free, this free-standing unit features an extensive 600mm jaw with a broad 30–200°C thermal range, pressing a massive 10mm wide, airtight weld across thick multi-ply materials up to 2 x 250 micron (1000 gauge).

Key Benefits:

• Ultra-Wide 10mm Heavy-Duty Seam: Delivers an extra-thick, burst-proof seal designed to contain bulk ingredients, hygroscopic powders, and heavy export hardware without rupturing.

• Direct Continuous Heat System: Maintains steady bar temperatures up to 200°C, providing the sustained thermal penetration required to fuse thick aluminium foils and multi-layer gusset folds that standard impulse sealers cannot weld.

• Hands-Free Foot-Treadle Actuation: Pedal-driven clamping leaves both hands completely clear to tension, guide, and support large, unwieldy sacks as the sealing jaws close.

• Expansive 600mm Sealing Span: Accommodates large-aperture agricultural sacks, coffee bags, and bulk foil crate liners in one continuous, airtight press.

• Granular 30–200°C Thermal Regulation: Variable thermostat dial lets operators dial in the precise heat required across diverse laminate barriers, cellophane wraps, and coated kraft papers.

Technical Specifications:

• Seal Length: 600mm

• Seal Width: 10mm

• Maximum Film Thickness: Up to 2 x 250 Micron (2 x 1000 Gauge)

• Temperature Range: 30°C to 200°C

• Heating Mechanism: Constant Direct Heat (Continuously Heated Jaws)

• Actuation Method: Mechanical Foot Treadle / Pedestal Stand

• Compatible Materials: Plain and Gusseted Aluminium Foil Sacks, Foil-Lined Bags, Coated Kraft Paper, Cellophane, and Heavy Multi-Layer Laminates

• Operation: Hands-Free Pedestal-Mounted Constant Heat Sealing

Why Buy This Product?

Standard impulse sealers cannot sustain the deep thermal saturation needed to weld through side gussets or thick aluminium foil bags, leaving hidden leak paths that ruin moisture-sensitive products. The Pacplus CCHS600 delivers sustained constant heat with foot-pedal mechanical clamping, forging an impermeable 10mm weld across multi-layered foil sacks to guarantee zero moisture ingress or transit blowouts.

Commodity: 8422300000
